Description
The GASMAX DSX gas monitor is an ideal solution for fixed ambient gas detection applications where multiple sensors are required.
The monitor is designed to detect a wide range of toxic and combustible gases in potentially hazardous environments.
The monitor operates on +18 to +32 volts DC and outputs an industry standard 4-20mA analog signal.
Optional programmable alarm relays allow the GASMAX DSX to operate with a wide range of industry devices and system controllers.
The GASMAX DSX supports both local and remote electrochemical and infrared combustible sensors.
Several electrochemical sensors, including hydrogen sulfide are available in low, medium and high ranges.
The GASMAX DSX features nonintrusive magnetic switches that allow complete system configuration, regular calibration and product maintenance to be performed in the field without compromising the explosion-proof rating.
The display screen always shows the current calibrated level of gas present at the sensor.
Features- Certified for use in Class I Div 1 hazardous areas
- Monitor toxic gases, oxygen levels or hydrocarbon combustibles
- Graphic display shows reading, alarm and fault conditions
- Supports both local and remote toxic or combustible sensors
- Non-intrusive magnetic interface for setup in hazardous areas
- Supports GDS-IR and GDS-IR2 hydrocarbon combustible detectors
- Dual independent channels support any combination of sensors
- Operates on +18 to +30 VDC
- Four programmable alarm relays
- Optional MODBUS wiring junction box
Configure
Specifications
Specifications
Brand
Certifications & Approvals
CSA Power Input
- +18 - 32 VDC, +24 VDC nominal
- Operating current 315 mA@ 24 VDC all options
- Transmitter only 50 mA @ 24 V, 65 mA @ 18 V
Display
- High resolution graphical LCD transflective (sunlight readable) screen with white LED backlight
User Interface
- Three magnetic switches for non-intrusive setup and calibration in hazardous areas
Sensor Input
- Supports local or remote toxic gas or infrared combustible / CO₂ using four-wire digital interface
Alarm Settings
- Two user-adjustable alarm settings
Standard Output
- Dual industry-standard 4-20 mA outputs; max 1000 ohm loop load
Optional Relay Output
- Four alarm / fault relays configurable for alarm set points; latching and non-latching mode; multi-sensor array logic
Digital Output
- Single isolated two-wire MODBUS serial slave port
Optional Radio
- No radio
Temperature
- Electronics -40°C to +40°C; Limits may vary depending on sensor
- Relative humidity 0-99% non-condensing
Housing
- Aluminum instrument housing, 303 Stainless Steel sensor housing
Dimensions
- 5.25” W x 5.3” L x 4.95” H (Transmitter only); Approx 6 lbs
- 5.25” W x 15” L x 4.95” H (Transmitter + GDS-IR); Approx 11 lbs
Certifications
- CSA: Class I Div 1 Groups B, C, D; T5
- IECEx: Ex d IIC TS Gb
- UL 2075 (when used with UL-Approved GDS-IR)
Sensor Warranty
- Varies with gas type (warranty subject to verification by GDS Corp)
Hardware Warranty
- One-year limited warranty
